Test and Measurement Equipment
Introspect SV3C
Through a collaborative agreement with Introspect, the UNH-IOL is using the Introspect SV3C for MIPI testing.
Introspect’s SV3C is a very small device, only weighing a pound or two, and it packs in a lot of performance. The SV3C allows us to test complete links on both D-PHY and C-PHY devices, and it contains automated suites for performing physical and protocol layer conformance tests. For example, for receiver testing, we can vary the analog signal parameters to either the D-PHY or C-PHY specifications, allowing precise control over timer values, skew and voltage levels as well as dynamic jitter injection.
Click on the link for more information on the Introspect SV3C.
Keysight Infiniium DSA9130A Digital Signal Analyzer
Through a collaborative agreement with Keysight Technologies, the UNH-IOL is using the Keysight Infiniium DSA91304A Digital Signal Analyzer for MIPI testing.
Combined with our D-PHYGUI software this platform provides the ability to capture and analyze D-PHY signaling in order to perform the UNH-IOL D-PHY Transmitter Physical Layer Conformance Test Suite.
For more information on the Keysight Infinium DSA91304A please visit Keysight Technologies.
Rohde & Schwarz RTO 1044 Oscilloscope
Through a collaborative agreement with Rohde & Schwarz, the UNH-IOL is using the Rohde & Schwarz RTO 1044 Oscilloscope for MIPI testing.
Combined with either our D-PHYGUI software or the Rhode & Schwarz Scope Suite software, this platform provides the ability to capture and analyze D-PHY signalling, in order to perform the UNH-IOL D-PHY Transmitter Physical Layer Conformance Test Suite.
For more information on the Rohde & Schwarz RTO 1044 Oscilloscope please visit Rhode & Schwarz.
The Moving Pixel Company P339-A
Through a collaborative agreement with The Moving Pixel Company, the UNH-IOL is using the Moving Pixel P339 Pattern Generator for MIPI testing.
The Moving Pixel Company’s P339-A is also a light, compact design. While the P339-A also offers control over physical layer signal characteristics, its focus for us has been precise control over protocol layer signal generation.
For more information on the Moving Pixel P339 please visit The Moving Pixel website.
Tektronix DSA72004B
Through a collaborative agreement with Tektronix, the UNH-IOL is using the Tektronix DSA72004B Digital Serial Analyzer for MIPI testing.
Combined with our D-PHYGUI software this platform provides the ability to capture and analyze D-PHY signaling in order to perform the UNH-IOL D-PHY Transmitter Physical Layer Conformance Test Suite.
For more information on the Tektronix DSA72004B please visit Tektronix.
